1012WCA·WGA
25 x 30 cm
Specification
| Sensor Type | a-Si TFT |
|---|---|
| Scintillator | CsI |
| Total Pixel Matrix (Pixels) | 2048 x 2560 |
| Active Area (mm) | 260 x 325 |
| Pixel Pitch (㎛) | 127 |
| Frame Rate (fps) | - |
| Energy Range (kVp) | 40 ~ 150 |
|---|---|
| Resolution (lp/mm) | 3.9 |
| A/D Conversion (bits) | 14 / 16 |
| Data Interface | GigE 802.11 a / g / n |
| Dimension (mm) | 337 x 395 x 18 |
| Weight (kg) | 2.7 |
- Product design and specifications are subject to change without prior notice to improve product performance.
- Downloads are only supported for customers who have filled out information.
- The image quality level may vary depending on the product usage environment.
- X-ray image acquisition and processing solution for animals
- Equips with the function to acquire the images of animal teeth.
- Improves the efficiency with upgraded user GUI.
- X-ray image acquisition and processing solution for animals
- An image viewer that can be interoperated with a detector
- Development of a professional tool considering the shooting environment for animals
