1417WCE

36 X 43 cm



1417WCE Series
  • 撮影部位および医療環境に最適化されたX線イメージングソリューション(4タイプ)

1417WCE 4가지 제품.gif











스크린샷 2025-05-12 오후 5.33.32.png









オプション1:高感度

  • Model Number : 1417WCE - HS
  • rayence の低線量ブランド Green ON Green ON

    • Green ON テクノロジー技術で患者と医療従事者の被ばく量を減少
    • 患者の被ばくを40%削減(自社第2世代製品対比)
    • 低線量撮影でも画像精度向上

オプション2:高解像度
  • Model Number : 1417WCE - HR
  • Picel Pitch : 100μm
  • Multipixel Technology
    • 100㎛検出器で140㎛検出器の感度を実現可能
    • 100㎛の高解像度に加え胸部、腹部など診断部位に合わせて140㎛の高SNRモードを選択可能
[용량낮춤] 1417WCE 홈페이지 업로드 2_비교.gif











[용량낮춤] GlassFree.gif





オプション3:ガラスフリー
  • Model Number : 1417WCE-GF
  • ガラス不使用のフレキシブルパネル搭載によって落下や衝撃に対する耐久性を向上
  • Multipixel Technology
    • 100㎛の高解像度に加え胸部、腹部など診断部位に合わせて140㎛の高SNRモードを選択可能



















医療用X画像ソリューション

  • 追加の利点







rayence_14717_1717WCE_promotion video_1.gif





医療用に最適化された設計

  • 多様な画像領域とお客様の環境に合わせてカスタマイズ
    • High Resolution, Low Dose, Glass Free
  • お客様の利便性向上と効率的なワークフロ


16時間バッテリー使用
  • バッテリー稼働時間最大16時間(デュアルバッテリ)
  • ホットスワップ機能で便利
  • 効率的なバッテリー:10分充電で40分稼働
[용량 낮춤] battery.gif
















高度な耐久性

  • 米国国防総省の耐久性標準試験(MIL-STD-810G)に合格(1417WCE-HR)
    • 1417WCE Standard Model 基準
  • Robust Design : Drop Height of 1.5m

IP67
  • IP67 防水
  • ほこりなど小さな汚染物質から保護できる設計
water proof_gray.gif













AcuDetect 2.gif



AccuAED
  • レイエンスのオリジナルオートトリガ搭載
  • 最小限のX線信号も検出して素早く画像取得
Application
仕様
センサータイプ

a-si TFT

シンチレータ

Csl : TI

合計ピクセルマトリクス(ピクセル)

3,534 X 4,302(100type)
2,500 X 3,052(140type)

有効エリア (mm)

353.4 X 430.2(100type)
350.0 X 427.3(147type)

ピクセルピッチ (㎛)

100 / 140

フレームレート(fps)

N/A

エネルギー範囲(kVp)

40 - 150

解像度(lp/mm)

5.0 lp/mm(100type)
3.5 lp/mm(140type)

A/D変換(ビット)

16

データインタフェース

Wired : GigE
Wireless : 802.11n/ac

サイズ (mm)

384 X 460 X 15

重さ (kg)

2.5
2.3(Glass free)

  • 本製品は医療機器であり、操作する前に安全説明をよく読んだ上で、遵守してください。
  • 製品の性能を向上させるため、製品の設計と仕様は事前通知なしに変更することがあります。
  • 情報を記入したお客様だけがダウンロード可能となります。
  • 画像の品質レベルは製品の使用環境によって異なる場合があります。
